OEM ODM Accept Smart AI Face Recognition Terminal Access Control Camera System
1. We accept OEM/ODM service.
2. We offer free SDK/API files for integration.
3. The device comes with IMX307 sensor, better image performance.
4. Our own developed face tracking exposure algorithm(linear mode), WDR≥110DB
5. Stable quality control, all electronic components used first-line suppliers.
| Model | B2002FR-8I-CM-TM-L06 |
| Hardware | |
| Processor | Dual Core Processor(Hi3516D V300)+ 1G memory + 16G flash |
| Operating system | Linux Operating system |
| Storage | Support TF card storage in the future ( only hardware interface reserved) |
| Viewing angle | Vertical viewing angle: 30°; Horizontal viewing angle: 30° |
| Sensor | 1/2.8" Progressive Scan CMOS(IMX307) |
| Lens | 6mm |
| Speaker | voice playback content can be customized |
| Temperature measurement performance |
| Measurement Environment | 16℃ - 40℃ (Indoor without wind, please refer to the end of the file) |
| Temperature measurement Lens | European original lens |
| Sensors type | Infrared Thermopile Medical-grade European imported sensors |
| Measurement accuracy | ±0.2℃ |
| Temperature resolution | 0.1℃ |
| Temperature measurement distance | ≤40cm |
| Measurement response time | 300ms |
| Performance | |
| Recognition height | 1.2~2.2 meters, angle adjustable |
| Recognition distance | 0.3~1.5 meters, depends on lens |
| Recognition time | Less than 0.5 seconds |
| Storage capacity | 160,000 capture records |
| Face capacity | 24000pcs |
| Screen brightness | ≥400 cd/m2 |
| Interface | |
| Switching output | 1 way switch output, other GPIO port can be customized |
| Network interface | 1 RJ45 10M / 100M adaptive Ethernet port, Gigabit Ethernet port can be customized |
| Wiegand interface | 1ch Wiegand interface input/output |
| RS485 | There is an RS485 interface on the PCB board, but no lead |
| USB interface | 1ch USB interface |
| Camera | |
| Camera | Dual cameras |
| Effective pixels | 2MP, 1920*1080 |
| Min Illumination | Color 0.01Lux @F1.2(ICR);B/W 0.001Lux @F1.2 (ICR) |
| SNR | ≥50db(AGC OFF) |
| WDR | 120db, ISP algorithm face partial exposure |
| Resolution | Main Stream: 50HZ: 25fps (1920*1080,1280*720) 60HZ: 30fps (1950*1080,1280*720) |
| Sub Stream: 720*576, 1-25(30)fps; 640*480, 1-25(30)fps; 320*240,1-25(30)fps; |
| Function | |
| Web side configuration | support |
| remote upgrade | support |
| Regular | |
| Working humidity | 0～90% relative humidity, no condensation |
| Salt spray | level Rp6 or above |
| Antistatic | contact ±6KV, air ±8KV |
| Powered | DC12V/2A |
| Device power | 20W(MAX) |
| Column aperture | 36mm |
| Equipment size | 252 (L) * 136 (W) * 26 (T) mm |
| Screen size | 8 inches IPS HD screen |
| Weight | 1.7 kg |
1. We offer free MQTT/HTTP files for integration.
2. Free Intelligent Face Access Management System.
3. Professional technical support for integration works.
We accept OEM for:
1. MOQ for software OEM is 100pcs.
2. MOQ for packing box OEM is 500pcs.
3. MOQ for hardware OEM is 500pcs, according to detailed request.
1. Customer: What’s your payment method?
We accept payment by credit card and T/T on Alibaba Trade Assurance and Paypal,
Western Union or as the method of custom.
T/T: 30% deposit, the balance needs to be paid before delivery
L/C: the balance need to be irrevocable L/C at sight
2. Customer: How do you ensure your quality?
We are ISO 9001factory with a strict inspection for each process.
3. Customer: What is the lead time?
Depends on the order quantity and detailed OEM request, normally 2-3 days for sample(Non-customized),
5-15 days for mass production.
